Interior Layout and Accommodations
Work Space Cabin
Furthest forward is open access to  ground tackle locker with work space area immediately aft with tool storage, bench and vise. Marine toilet / Head, pump and holding tank also located to port in workspace area followed by a sitting, storage area to port, hanging lockers to starboard and bookshelves on one the foreword bulkheads.

Main Cabin
Next aft is the main cabin, with settee berths (port and starboard) along with storage lockers located outboard and above the bunks.  The starboard settee can be widened with an insert to create a double berth. A dining table, with storage and folding leaves is centered between the two settees.
Continuing aft in the Main Cabin is the Galley Area with a porcelain sink (aft) provided with both fresh and salt water via dedicated hand pumps. Cooking maybe done on either a 3-burner Shipmate kerosene stove and oven located to port and forward in the Galley Area or by use of a Shipmate wood / coal burning stove with oven both located outboard of the galley counter and sink. Opposite (to starboard) of the stoves and sink is a large well-insulated, under-counter ice box  and galley pantry locker and continuing aft (along the starboard side) is the passageway to the aft cabin.

Aft Cabin
Navigation station located forward and to port in the Aft Cabin with hanging and storage lockers to starboard. The main engine is located on center line between the navigation station (to port) and lockers (to starboard) with the top of the engine box making for a comfortable seat either to attend to the ship’s navigation or a place to don your sea boots before venturing up the companionway (aft) to the cockpit.
Finally there are quarter berths (port and starboard) towards the aft end of the Aft Cabin with storage lockers above and outboard of the berthing spaces.

Hull, Deck and Cabin Construction
Full keel with cut-away forefoot and keel-hung rudder underwater configuration
Copper rivet fastened, Mahogany hull planking and transom over Oak frames, stem, back bone, etc.
Cast Iron ballast keel
Solid Mahogany plank rudder with bronze strap pintles and gudgeons
White Pine decks (painted) over Oak deck frames and carlins
Varnished Mahogany king plank, covering boards and margin planks
Varnished Teak cap rails
Varnished solid Mahogany cabin sides with dovetailed corners
Marine plywood cabin tops with fiberglass cloth overlay and painted finish

Deck Hardware and Features (aft to fore)
Bronze main sail sheet  traveler
Bronze stern line hawse(s) port an starboard
Bronze rod stern cleats port and starboard on inner-boomkin
Lazarette locker mushroom vent
Bronze sockets for main boom gallows
Lazarette locker hatch
Emergency rudder post / tiller head
Varnished Locust lifeline stanchions port and starboard
Cockpit with steering, engine control, helm compass and sheet winches (port and starboard coamings
Aft cabin with sliding companionway hatch, varnished teak handrails, bronze opening ports (4ea) and cabin heater chimney / “Charlie Nobel”
Spring line cleats and hawse(s) port and starboard
Bronze foresail sheet traveler
Forward cabin with sliding companionway hatch, butterfly opening hatch, varnished teak handrails, Bronze opening ports (8ea) and cabin heater chimney / “Charlie Nobel”
Bronze staysail sheet traveler
Forepeak scuttle hatch with opening hatch, bronze opening ports (2ea) in hatch sides and fixed port with Bronze trail ring in hatch top.
Bronze bow / anchor line cleat
Bronze anchor windlass
Bronze mushroom vent for chain locker
Bow sprit with head sail fitting, staysail fitting and support rigging
Anchor rollers port and starboard of bow sprit

Spars and Rigging
Schooner rigged with Marconi main sail and   Gaff-Headed fore sail
Glued solid Spruce masts (Main and Fore) with varnished finish stepped on keel
Solid Spruce booms (Main and Fore) with varnished finish
Solid Spruce gaff (Fore) with varnished finish
Solid Spruce self-tacking staysail club with varnished finish
Solid Spruce bow sprit and boom kin with painted finish (White)
Stainless steel standing rigging with bronze bottle screw adjusters
Traditional 3-strand Dacron running rigging
Bronze travelers for main sail, fore sail and self-tacking jib sheets
Primary Sheet Winches: Lewmar #48 Bronze, two-speed, self-tailing
Secondary Sheet Winches: Lewmar #44 Bronze, two-speed, self-tailing
Halyard winch
Reefing / Outhaul Winch: South Coast Bronze single-speed

Sails and Canvas
All sails Dacron cloth
Main Sail
Fore Sail
Staysail
Jib
Sail Covers

Propulsion and Fuel Systems and Equipment
Auxiliary Propulsion: Westerbeke / Perkins 4-236, 4-Cylinder, 85HP diesel engine
Engine panel with status gauges for oil pressure and amperage in cockpit
Kobelt Bronze single-lever engine control for throttle and transmission in cockpit
Engine shut-off in cockpit
Groco raw water filter / strainer
Traditional Bronze flax-packing style stuffing box
Shaft log with cutlass bearing
Stainless steel propellor shaft (2”)
Bronze propellor, fixed 2-blade.
Total Fuel Capacity: 150 Gallons
Two (2ea) fuel storage tanks  (75 gallons each) in bilge areas
One (1ea) fuel day tank (15 gallons)
Racor fuel / water separator filter

Steering Equipment
Varnished Teak and Mahagony spoked steering wheel
Edson worm gear steering system
Bronze rudder post
Solid Mahogany and Bronze strap rudder
Keel-hung rudder with bronze pintles and gudgeons
Bronze tiller head in cockpit for emergency steering
Autohelm 6000 autopilot
Aries Wind Vane steering

Electrical Systems and Equipment
12-Volt DC ship’s systems
Separate battery banks for engine start and ship’s systems
Perko 4-position main battery switch
12-Volt DC circuit panel
Heart Interface Model HF-600-12 Inverter

Electronics and Navigational Equipment
Helm Compass: Danforth Constellation in Edson Bronze and cut-glass binnacle in cockpit
Tell-Tale Compass: Danforth Constellation in forward cabin
Garmin GPS / Chart plotter
Aquameter Super Cheater depth sounder
VHF Radio
Autohelm 6000 autopilot
Weems and Plath ships clock (forward cabin)
Weems and Plath ships clock (aft cabin)
Weems and Plath barometer (aft cabin)

Plumbing and Sanitation Systems and Equipment
Freshwater Capacity: 125 Gallons
Porcelain galley sink
Manually operated freshwater hand pump
Manually operated saltwater hand pump
Manually operated marine toilet
Marine toilet plumbed for discharge overboard or discharge to holding tank for shore side pump out.
Bladder-style black water tank / never used
Blackwater Capacity: 14 Gallons (approximate)

Ground Tackle Systems and Equipment
Anchor rollers port and starboard on bow sprit
Primary Anchor: Rocna 55 lb. plow-style anchor with 200’ chain
Additional Anchor: 60 lb. Danforth-style anchor
Additional Anchor: Fisherman-style folding anchor
Several additional chain & rode combinations
Bronze two speed anchor windless

Dewatering Equipment
Whale Gusher 30 high-capacity manual bilge pump

Additional Equipment
Docking lines and fenders
Boat hook
Cape Dory sailing dinghy (11’)

Recent Work and Upgrades
2022: Refurbished aft fuel tanks
2012 Stainless steel fresh water tank 2012.
2010: Frame repair by Belfast Boatworks
2008: New foremast stainless shrouds
2005: Keel bolts were replaced
